_ USING THE HARNESSING SySTEM
44
Take care that your child is always strapped in, with the buckle fastened,
whenever you go out with the pushchair.
Adjust the straps so that they are taut and lie close against the child.
To adjust the strap length, slide the strap clasps up or down. Check that
the straps are not twisted.
The childproof lock is on the back of
the buckle. This can be activated and
deactivated by turning.
Activating the childproof lock locks
the buckle opening mechanism.
wARNING!
• Alwaysusetheshoulderandwaiststrapstogetherwiththecentre
strap.
Feed the centre strap with the buckle between
thechild’slegs.Theninsertthebuckle
adaptors on the shoulder and waist straps
from above into the top of the buckle. They
should click audibly into position.
Shoulder strap
Centre strap
To open the harness system, press the button
in the middle of the buckle until the buckle
adaptors are released..
Waist strap
