25 | Modbus Installation
Variable
Name
Description
Addr.
Type
Format
Range
Unit
R/W
Details
Set2Cyl2
Writes the
desired space
setpoint for
control channel
2 for cylinder 2
41010
Holding
Register
Integer
30-95
%
Write
Use only with NHTC-
150 and NHTC-200
models when sending
RH value to RHDem2
with dual channel
control enabled and
cylinders are in
independent operation
mode
DisableCyl1
Remotely
disable steam
production for
cylinder 1
40262
Holding
Register
Integer
0 or
255
-
Write
0 = Normal operation
255 = Disabled
DisableCyl2
Remotely
disable steam
production for
cylinder 2
41262
Holding
Register
Integer
0 or
255
-
Write
Used only for NHTC-
150 and NHTC-200
models. Both cylinder
1 and 2 must be
disabled to completely
disable humidifier.
0 = Normal operation
255 = Disabled
NetSensor
Switches
between hard
wired or
network control
signal
40226
Holding
Register
Integer
0 or 1
-
Write
1= Network sensor or
demand
0 = Wired sensor or
wired demand
Ch1DemCyl1
Displays
channel 1
demand for
cylinder 1
30348
Input
Register
Integer
0 - 100
%
Read
Displays channel 1
demand as a
percentage of cylinder
capacity for cylinder 1
Ch1DemCyl2
Displays
channel 1
demand for
cylinder 2
31348
Input
Register
Integer
0 - 100
%
Read
Displays channel 1
demand / output as a
percentage of cylinder
capacity for cylinder 2
(NHTC-150 and NHTC-
200 models only)
Ch2DemCyl1
Displays
channel 2
demand for
cylinder 1
30349
Input
Register
Integer
0 - 100
%
Read
Displays channel 2
demand as a
percentage of cylinder
capacity for cylinder 1
Ch2DemCyl2
Displays
channel 2
demand for
cylinder 2
31349
Input
Register
Integer
0 - 100
%
Read
Displays channel 2
demand / output as a
percentage of cylinder
capacity for cylinder 2
(NHTC-150 and NHTC-
200 models only)
Fault Warning
Reads fault
status
30301
Input
Register
Integer
0 or
255
-
Read
0 = No Fault
255 = Fault Warning
Service
Warning
Reads service
warning status
30300
Input
Register
Integer
0 or
255
-
Read
0 = No Service
Warning
255 = Service Warning
Unit Status
Reads unit
status
30312
Input
Register
Integer
0 or
255
-
Read
0 = Idle / Standby
255 = Active /
Humidifying
Cyl1OpTime
Reads operating
time for cylinder
1
30213
Input
Register
Integer
0 -
65535
5
min
Read
Reads operating time
for cylinder 1. Each
number is equivalent
to 5 minutes of
operation.
Time in hours = (Value
x 5)/60
