PV11 SPECIFICATIONS
Gain: Phono stage 47dB *
High level 18 dB
Output: Maximum 20V
Phase: Line stage inverts phase of all inputs.
Phono overload: in excess of 200 mv at 1KHz *
Response: bandpass 2Hz to more than 100 KHz
RIAA equalization to +/- .25dB (20Hz-20KHz) *
Hum and noise(20Hz-20KHz): phono 78 dB below 10mv input *
Line level:92 dB below 2.5V output
Distortion: THD less than .25%
IMD less than .25%
Ouput impedance: less than 500 ohms
Dimensions: 19"W x 3.5"H x 12.5"D
Weight: 13 lbs.
FUSE: The AC line is fused to protect the PV11’s transformer. This fuse
will not fail in normal operation. Failure of the fuse is a symptom of a
more serious problem, indicating the need for qualified service. IN NO
EVENT SHOULD THE FUSE BE REPLACED WITH A FUSE OF
DIFFERENT TYPE OR RATING THAN THAT SUPPLIED BY THE
FACTORY. The PV11 uses a 3/4 amp 3AG slo-blow fuse (1/2 amp 3AG
slo-blow for 220V operation).
* Applies on ly to PV11 equipped with phono stage
PV11 and PV11L Owner’s Manual 11
