PV11 Tube Complement
V1 AND V2 type 12AX7
V3 type 5751
V4 - V6 type 12AU7
NOTE: PV11L uses only tubes V5 and V6
V1 V2
V5 V6
V3
V4
PV11 and PV11L Owner’s Manual 8
