SAFETINEX

SAFETY LIGHT CURTAINS

HAND PROTECTION, TYPE 2

INSTRUCTION MANUAL

Table of Contents

Questions and Answers

L
Linda HuynhAug 3, 2025
What to do if Contrinex SAFETINEX Security Sensors OSSD1 and OSSD2 LEDs remain on in red?
- P
  Pamela WelchAug 3, 2025
  If the OSSD1 and OSSD2 LEDs on your Contrinex Security Sensors are constantly red, it indicates that the protective field is obstructed, the alignment is poor, or a fault has been detected. First, remove any objects blocking the protective field. If the problem persists, realign the sender and receiver units. As a last resort, try power cycling both units by switching the power supply off and on again.
M
Margaret BrownAug 8, 2025
What to do if Contrinex SAFETINEX Security Sensors OSSD1 and OSSD2 LEDs remain red and sender’s LEDs are off?
- R
  Rhonda AdkinsAug 9, 2025
  If the OSSD1 and OSSD2 LEDs are red while the sender's LEDs are off (excluding the power LED) on your Contrinex Security Sensors, it could be due to an OSSD short-circuit or a device malfunction. Ensure that the OSSDs are not shorted together or connected to 0V or 24VDC. If the issue continues, the unit may need to be returned for revision.
A
Adam HaleAug 14, 2025
Why Contrinex SAFETINEX Security Sensors power LED (receiver) does not light up?
- J
  Joe SimpsonAug 15, 2025
  If the power LED on the receiver of your Contrinex Security Sensors isn't lighting up, it means there's either no operating voltage or the voltage is too low. Check the voltage supply to resolve this issue.
M
Melissa GainesAug 21, 2025
How to fix orange alignment LED blinking on Contrinex Security Sensors?
- L
  Lisa WilliamsAug 21, 2025
  If the orange alignment LED on the sender of your Contrinex Security Sensors is on or blinking, it signifies poor alignment of the protective device. To fix this, follow the alignment instructions to properly align the protective device.
H
heatherclarkAug 27, 2025
How to disable test mode on Contrinex SAFETINEX?
- M
  Martha RamirezAug 27, 2025
  If the yellow 'test' LED is lit on the YBB sender of your Contrinex Security Sensors, the protective device is in Test Mode. To disable this mode, connect the test input to 24 V.

Summary

AOPD Advantages and Operating Principle

Operating Principle of Light Curtains

How Safetinex light curtains and access control barriers operate using infrared beams.

North American Safety Standards

OSHA Regulations and US Consensus Standards

Risk Assessment and Determination

Hazards and Risk Reduction Strategy

Definition of hazards and risk reduction strategy as per EN/ISO 12100.

Risk Assessment Process Steps

Steps for risk assessment: hazard identification, harm severity evaluation, and solution implementation.

Risk Assessment Process Diagram

Flowchart illustrating the iterative process of risk analysis and assessment for machine hazards.

EN;ISO 14121 Hazard and Risk Assessment

Methods for Determining Risk Level

Methods for assessing machine risks, including relevant standards and corrective measures.

Risk Level Determination in North America

Determining Required Performance Level (PL)

Procedure for selecting safety measures and determining the required Performance Level (PL).

Required Performance Level Diagram

Installation and Safety Distances

General Installation Rules

General rules and concepts for installing safety light curtains and access control barriers.

Positioning the AOPD Unit

Importance of AOPD positioning for safety and preventing bypass.

Minimum Safety Distance Required

Methodology for determining minimum safety distance based on approach speed and system response time.

Safety Distance Evaluation Process (EU)

Minimum Safety Distance Calculation (EU)

Formula and factors for calculating minimum safety distance in the EU.

EN;ISO 13855 Safety Distance Standard

Defines the basic formula for calculating minimum safety clearance between the protective device and hazardous location.

Minimum Safety Distance Calculation (US & Canada)

General safety distance calculation formula for US and Canada.

Technical Documentation and Principles

Operating Principle Explained

Self Protected Outputs (OSSDs)

Installation Procedures

General Installation Considerations

Factors for installation: reflective surfaces and protective screen positioning.

Minimum Safety Distance Calculation

Importance of calculating minimum safety distance in compliance with regulations.

Positioning Sender and Receiver Units

Guidelines for vertical, horizontal, and L-shaped installations of sender and receiver units.

Distance from Reflective Surfaces

Mechanical Installation Details

Mounting Brackets and T-Nuts

Electrical Connections and Compatibility

Connecting the Protective Device

Instructions for electrical connections, emphasizing the need for qualified personnel.

Power Supply Requirements

Pin Assignment and Safety Relay

M12 Connector Pin Assignment

M12 connector pin assignments for emitter and receiver units.

Safetinex Safety Relay YRB-4 EML-31 S

Response Time to Safety Relay Switching

Understanding safety chain delays for accurate minimum safety distance calculation.

Connection Examples for Safety Relay

Automatic Restart Mode Connection

Alignment and Commissioning

Alignment of Sender and Receiver Units

Ensuring accurate alignment of sender and receiver units for proper function.

Test Before First Commissioning

Performing a functional test before initial commissioning to ensure proper operation.

Testing and Maintenance

Daily Functional Test Procedure

Daily functional test procedure for Safetinex YBB models using a test rod.

Troubleshooting Common Malfunctions

Troubleshooting chart for common malfunctions based on LED display and potential causes.

Preventive Periodic Inspections

Contrinex SAFETINEX Specifications
