INSTALLATION
51mm
2"
26mm
1"
22mm
7/8"
19mm
3/4"
72mm
2.83"
C
B
A
GREEN
Printed in Canada 09/2013
BLUE
RED
BLACK
C
B
A
R
R
~
~
~
~
BROWN
BROWN
ORANGE
KLQ-Kit
(Option)
JSC-88A with KLQ-Kit
(Optional remote light kit only with JSC-88A)
Side view
Rear view
Front view
60mm
2.36"
100mm
3.94"
Name plate used
as a drill guide
24.5mm
31/32"
13mm
33/64"
49mm
1 15/16"
It is recommended to use shielded
wiring for the installation of the
optional remote light kit (KLQ-Kit).
M
OR
MC
F
DS
BLUE
RED
BLACK
C
B
A
M
OR
MC
F
DS
JSC-88 or JSC-88A
DS:
F:
MC:
OR:
M:
Disconnect
Switch
Fuses
Magnetic
Contactor
Overload Relay
Motor
K6 or KA: Voltage Reducer Kit
A
VOLTAGE DETECTOR
B
C
High-Quality Solution
A full 2-year warranty
UL ( ) and CSA certified
Encased in epoxy, hence 100% resistant to hostile, humid and dusty
environments
High Sensitivity
Can detect and indicate any current leakage greater than 2mA
Easy-to-install
Meets NEMA-4X certification (standard)).
For more informations, see « Specifications »
High Luminescent Visual Indicator
Since the indicators are luminescent (special low-current LEDs),
readings are not affected by ambient light. They can be seen
regardless of their placement on the MCC (motor control center).
Normal Operating voltage
The JSC-88 or JSC-88A comes with a universal voltage reduction kit
that permits operation from 208 volts to 600 volts.
Max. current consumption
1.9 mA
Dimension
72mm X 51mm X 26mm
NEMA-4X
Indoor or outdoor use primarily to provide a degree of protection against
corrosion, windblown dust and rain, splashing water, hose-directed
water, and damage from external ice formation.
IMPORTANT NOTE: Concerning installation of the JSC-88A
For a proper and safe operation, the JSC-88A requires a link to neutral
(or ground where permitted).
On a true floating systems, to use the JSC-88.
ORDERING INFORMATIONS
NEMA-4X Series For "Y" or "Delta" systems with ground
JSC88A Standard unit for 208 volts c/w KA reducer kit
KA Voltage reducer kit (208 to 600 volts) for JSC-88A
KLQ-Kit Optional remote light kit only with JSC-88A
JSC-88 Standard unit for 208 volts c/w K6 reducer kit
K6 Voltage reducer kit (208 to 600 volts) for JSC-88
SPECIFICATIONSSPECIFICATIONS
FEATURES
(See IMPORTANT NOTE for connection)
(See IMPORTANT NOTE for connection)
Connection to neutral
(or ground if is permitted)
Connection to neutral
(or ground if is permitted)
US
C
R
(N) or ( )
(N) or ( )
KA
K6 ou KA
C
A
B
C
A
B
