a) Umbrella frame with canopy x 1
b) Lower pole x 1
c) Finial x 1
STEP 1
Take all parts out of the box and
ensure they are all present.
STEP 2
Screw the nial into the pre-drilled hole
at the top of the canopy. Ensure nial is
secure, do not overtighten.
STEP 3
To assemble the umbrella, screw the top
pole into the bottom pole until secure.
STEP 4
To open the umbrella, pull the cord down
until the canopy is up past the pin hole, place
the stop pin into the desired hole to hold the
umbrella in place.
To close the umbrella, remove the stop pin
and lower the canopy down, making sure you
keep hold of the pulley cord whilst doing so.
STEP 5
You can tilt the umbrella by pressing
the tilt button. Hold onto the top
section of the pole as you do this.
a
b
c
ASSEMBLY GUIDE
Ensure canopy is closed when not in use. Close in windy conditions or when a storm approaches.
Never allow the umbrella to ap in the wind; this could damage the canopy.
