CORBERO CT M 30 - Page 20

2.2 Brief introduction of product structure
2.3 Internal Wire Diagram
WIRING DIAGRAM
Thermal
Cut Out
Thermostat
Power Supply Indicator Light
Heating Indicator light
Heating Element
Switch
Brown
Blue
Yellow/Green
E
N
L
B
D
A
C
(Note:All dimensions are in mm)
A
B
C
D
CT M 30
340
576
340
200
CT M 50
385
710
385
200
CT M 80
450
745
450
200
CT M 100
450
896
450
200
Thermometer
Hot water outlet
Cold water inlet
On/ Off
Temperature
adjusting knob
Inner tank
Thermal
insulation
Heating
element
Anode
Shell
Power
indicator
light
Heating indicator light
4
CT M 120
450
1048
480
200
