Installation and Service Manual
© 2004, IMI Cornelius Inc. - 15 - Publication Number: 710160089
UCC-40 PARTS LIST
Item New Part No Description Old Part No. Torrington Part
No.
1 26-0064 Cabinet Ass’y 119-178-007
2 26-0146 Coil Ass’y - Freon 119-184-001
3 55-0339 Control - Temperature 155-969-000 186074001
4 23-0218 Plate - Compressor (1/3 hp) 119-066-004
5 35-0128 Power Cord (115v) 119-360-000
35-0124 Power Cord (220v) 115-558-000
6 55-0087 Condenser 101-434-000
7 23-0510 Shroud - Fan 115-194-000
8 35-0015 Blade - Fan 105-240-000
9 35-0094 Motor - Fan (115v) 119-646-000
35-0097 Motor - Fan (220v) 119-805-220
10 23-0302 Handle 119-118-000
11 23-0040 Bracket - Agitator Motor 115-659-000
(2 Required)
12 40-0411 Washer 106-141-000
13 35-0078 Motor - Agitator 115v 119-447-009
35-0079 Motor - Agitator 220v 119-447-229
14 23-0107 Bracket - Fan Motor 103-024-000
15 55-0031 Bushing 103-067-000
16a 26-0360 Compressor Ass’y 1/3hp 115v
35-0148 Relay 1/3 hp 115v 101-049-000
35-0104 Overload 1/3hp 115v 101-050-000
16b 26-0366 Compressor Ass’y
1/3hp 220v/50hz
35-0151 Relay 1/3hp 220v/50hz 119-803-001
35-0106 Overload 1/3hp 220v/50hz 119-803-002
16c 26-0362 Compressor Ass’y
1/3hp 220v/60hz
35-0152 Relay 1/3hp 220v/60hz 119-803-261
35-0107 Overload 1/3hp 220v/60 hz 119-803-262
17 23-0419 Lid Gray 119-165-007
18 26-0061 Bulb Holder 112-544-675
(Temperature Control)
23-0064 Bracket - Bulb Holder 119-791-097
19 26-0058 Blade - Agitator 115-790-001
20 40-0252 Pin - Cotter S.S. 106-140-000
21 40-0262 Plug - Cap 113-035-000 31699012
22 23-0130 Bracket - Line 119-185-707
23 55-0033 Bushing 119-426-875 34065
24 23-0208 Basket - Product Coil 119-192-001
25 65-0085 Tube - Vinyl 104-299-000
26 40-0019 Clamp 108-111-000 48114005
27 65-0047 Tube - Insulation 3/8 I.D. 104-249-000
28 40-0081 Connector S.S. 3/8 MPT x 3/8B 115-576-000 77081400
29 40-0243 Fitting - Compression 119-688-002
3/8 Tube x 3/8 MPT
30 55-0275 Pump S.S. 50 GPH 107-776-000
31 55-0215 Cover Insulation (Left) 115-396-000
32 55-0214 Cover Insulation (Right) 115-395-000
33 40-0249 Nut - Pack 3/8 119-689-000
34 40-0297 Screw 110-861-902 718400297
35 35-0035 Clamp V c/w Bolt 100-361-000 20543
36 35-0115 Pin - Hitch 101-046-002
37 35-0072 Motor 1/3hp 115v 115-442-000 60030058
35-0075 Motor 1/3hp 220v 50/60hz 115-442-220 71860673
38 40-0208 O Ring 103-123-000 31525012
39 26-0136 Coil Assembly CO2 Water 119-993-728
40 23-0231 Cover - Electrical Box 119-446-001
41 23-0819 Wrapper Electrical Box 115v 119-465-006
23-0783 Wrapper Electrical Box 220v 119-465-001
42 35-0062 Control - Liquid Level 115v 110-863-000
35-0065 Control - Liquid Level 220v 50/60hz 110-863-220 60439010
43 40-0288 Screw 103-462-000
To Next Page
