Installation and Service Manual
© 2004, IMI Cornelius Inc. - 1 - Publication Number: 710160089
IMPORTANT INFORMATION AND SAFETY NOTES. PLEASE READ BEFORE
INSTALLING DISPENSER.
• Always transport equipment in an upright position and never drag over rough floors or down steps.
• A trained person, who is qualified to make connections to water, electrical and/or compressed gas
supplies must only carry out installation and maintenance. Local by-laws/regulations must be
followed.
• Switch off and unplug electrical power to unit during maintenance operations. Do not attempt to
remove any protective covers.
• Locate equipment on a firm, level surface and protect from physical damage. Mounting surface must
be able to support 500 lbs. (227kg) weight. Never allow air vents/louvers to become blocked and do
not place any non-specified items on top. Regularly clean condensers and louvers with a soft brush or
vacuum.
• This dispenser is for indoor use only. Do not expose equipment to extremes of temperature, water
spillage, spray, steam, or high humidity or clean with water jet into dispenser components because
this could cause damage to electrical components and shock to personnel. Do not place or store
objects on top of unit.
• This dispenser must be connected to correctly rated electrical power outlet, preferably protected by a
safety cutout and is easily accessible for isolation of the equipment. The equipment must be earth
grounded.
• Use and ELCB (earth leakage circuit breaker)/GFCI (ground fault interrupt) for electrical power
protection.
• Use an HVAC circuit breaker to the power outlet circuit supplying the dispenser.
• Each module or accessory requires a 120 VAC 15 Amp 60 HZ grounded outlet. If 230 VAC 50/
60 HZ, use a minimum of 10 Amp outlet for each module or accessory.
• Ambient temperature must not exceed 90
o
F (32.3
o
C) on units with merchandisers.
WATER SYSTEM
• Insufficient water supply to carbonator will cause pump damage.
WARNING: If the installation is idle and exposed to freezing temperatures, disconnect water
supply lines and blow out all water from pump, carbonator tank, and dispensing system.
WARNING: UNDETECTED CO2 LEAKS MAY CAUSE HARM OR DEATH DUE TO ASPHYXIATION.
CO2 tank must be located next to a solid wall and chained to the wall. CO2 cylinders must be
secured in a vertical position and only connected to dispensing equipment via a suitable
pressure regulator. Check connections for leaks.
WARNING: DO NOT lift dispenser modules by valve housing assemblies. Lifting by the valve
housing assemblies will cause damage to the housing.
WARNING: System must be sanitized in accordance with the procedures found in this manual
under the cleaning and maintenance section.
WARNING: Before attempting to remove the refrigeration deck, disconnect all electrical power.
Melt the ice bank and thoroughly drain the water bath. See additional notes in Water Bath
Cleaning Section in the manual.
