Corsair 750D User Manual



 
> Locate and remove the two screws securing the
cage to the base on the bottom of the case.
> Pull the HDD cage out.
> HDD cages are stackable and can be installed on top of
each other or completely removed for improved cooling.
Note: The HDD cage can also be removed by removing the four
screws located directly under the base on the bottom of the case.
How to remove the HDD cageHow to remove the SSD caddy
> To remove the SSD caddy, locate the center tab to the right
of the caddy and then pull the tab in and lift to release the caddy.
> To install the SSD caddy, align the SSD caddy with the holes
from left to right and secure into place.

Corsair 750D Specifications

General

Type	Full Tower
Material	Steel, Plastic
Expansion Slots	9
Weight	9.7 kg
Maximum GPU Length	450mm
Maximum CPU Cooler Height	170mm
Maximum PSU Length	225mm
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Dimensions	560mm x 546mm
Drive Bays	3 x 5.25"
Cooling Support	Front: 2 x 140mm or 3 x 120mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 140mm or 120mm, Bottom: 2 x 120mm
Included Fans	Front: 2 x 140mm, Rear: 1 x 140mm
Radiator Support	Top: 120/240/280/360mm; Rear: 120/140mm
Front I/O Ports	2 x USB 3.0, Audio in/out
