Corsair PLATFORM 6 - Tools and Hardware

T
R
U
F
D
D
C C
C
G
AB
B
B
E1 E2
R
SCAN ME
Tools and Hardware
OUTILS ET MATÉRIEL | WERKZEUGE UND HARDWARE | VÆRKTØJ OG BEFÆSTIGELSE | HERRAMIENTAS Y TORNILLERÍA | FERRAMENTAS E HARDWARE
x2
WING NUT
SCREWS
x4
M6 BOLTS
15mm
x2
M6 BOLTS
10mm
x16
M8 BOLTS
15mm
STEP 1 HARDWARE STEP 2 HARDWARE STEP 3 HARDWARE STEP 5 HARDWARE STEP 6 HARDWARE
x2
M6 BOLTS
15mm
x2
M4 BOLTS
15mm
x6
M6 BOLTS
10mm
x4
WOODEN
DOWELS
x2
RATCHETING
BOLTS
x2
M8 BOLTS
15mm
x4
M6 BOLTS
15mm
x4
M6 BOLTS
10mm
x10
M6
BLACK
T-NUTS
x6
¼ x 20
SILVER
T-NUTS
BLACK T-NUTS SILVER T-NUTS TIES SPARE PARTS (Extras)
x10
ZIP TIES
x10
VELCRO
TIES
x2
WOODEN
DOWELS
x3
T-NUT
SET SCREWS
CHECK OUT OUR
ONLINE ASSEMBLY GUIDE
CONSULTEZ NOTRE GUIDE
D’ASSEMBLAGE EN LIGNE
MONTAGEANLEITUNG ONLINE LESEN
SE VORES ONLINE SAMLEVEJLEDNING
CONSULTE NUESTRA GUÍA DE
MONTAJE EN LÍNEA
CONSULTE O NOSSO MANUAL DE
MONTAGEM ONLINE
qsg.corsair.com/platform6
1
STEP
