1910000000349 - nv00
C
D
ORLO - CAMPO
A B
mm mm
1040 580
1320 580
1600 580
1880 580
MARZIO - NELLA
A B
mm mm
965 580
1245 580
1525 580
1805 580
ORLO M - CAMPO M
A B E
mm mm mm
1040 580 265
1320 580 265
1600 580 265
1880 580 265
MARZIO M - NELLA M
A B E
mm mm mm
965 580 265
1245 580 265
1525 580 265
1805 580 265
C D
mm mm
B-30 A-200
B
E
50
E
I = B-30
≥110
A
79-91
64-76
B
E
50
E
≥110
A
79-91
64-76
I = B-30
COSMO GMBH - Brandstücken 31 - 22549 Hamburg - Tel: +49 40 80030430 - www.cosmo-info.de
1
2 3
4 5 6
ORLO M
CAMPO M
MARZIO M
NELLA M
x2
