25. SYSTEM STARTUP TEST
The test must be carried out once installation is completed and the wiring and configuration have
been executed and checked.
Using the + and – keys, select:
• output to be tested:
– Y1 MODUL. or Y1 2 STAGES or Y1 3 STAGES: depending on M2.
3 setting .
– Y2 MODUL. or Y2 2 STAGES or Y2 3 STAGES: depending on M2.
5 setting .
– PUMP M1 ;
– PUMP M2 ;
– Ys ;
• status :
– with Y...MODUL. : IDLE ; CCLOSES ; OPEN
– with Y.. 2 STAGES : ON 1 ; ON 1+2 ; OFF.
– with Y.. 3 STAGES : ON 1 ; ON 2 ; ON 1+2 ; OFF.
– with Ys : 0 VOLT ; 5 VOLT ; 10 VOLT.
– with PUMP M1 and PUMP M2 : ON ; OFF.
Check results.
M3.1
O u t p u t : Y 1 M O D U L .
S t a t u s : I D L E
24. ALARMS
The controller processes two types of alarms:
– alarms related to functional irregularities affecting the controller and the controlled systems
(LED 6.
10)
– alarms related to short and open detector circuits (LED 6.
8)
Alarms are signaled by LEDs located on the controller’s front panel. On the display page alarms are
identified by a letter “A” flashing alternately to the number corresponding to the relevant alarm.
Alarms can be transmitted to a local and/or a central telemanagement computer through the C-Bus
connection.
24.
1 Functional alarms
Functional alarms occur when there is a continuing deviation between actual and desired measures.
These alarms do not affect the controller’s proper operation.
“By default” all alarms are disabled except clock alarm (8)
Use the + and – keys to enable desired alarms, entering numbers in place of the dashes.
Number flashing = the alarm is on
IAlarm limit values and delays can only be changed via computer.
Types and reasons of alarms:
1 = flow temperature difference (if only B1 is connected)
–for actual temp. lower than T°fHea when Y..: Heating
or higher than T°fCoo when Y..: Cooling
3 = room temperature difference (if B3 is connected)
–for actual temp. lower than T°rHea when Y..: Heating
or higher than T°rCoo when Y..: Cooling
4 = preheating temperature difference (if B4 is connected and when Y..: Pre-heating)
– for actual temp. lower than desired value
8 = internal clock cannot be disabled
– when the clock assumes inconsistent values
24.
2 Detector alarms
Detector alarms occur when there is a short circuit or open circuit affecting the connected de
-
tectors.
The effect of alarm situations is delayed by one minute.
By default” all alarms are disabled.
Use the + and – keys to enable desired alarms, entering numbers in place of the dashes.
Types and effects of alarms:
1 = flow temp. detector (B1): valve stops where it is
2 = outside temp. detector (B2): valve stops where it is
3 = room temp. detector (B3): valve stops where it is
4 = preheating temp. detector (B4): valve stops where it is
M2.10
A l a r m s F u n c t i o n .
– – – 8
M2.11
A l a r m s D e t e c t o r
– – – –
