Open and Assemble:
1. Release the locking latch, unfold the stroller upwards and make sure
snap the lock into place.
2. Insert leg into the front wheel
until a “click” is heard.
3. As shown in Figure 3-1, put the washer, brake, washer and rear wheel
through the wheel rod in order, then put another washer, fix the wheel
with a clip, and cover the cap. Repeat this installation for the other
side.
4. Connect the rear wheels to the
rear legs until a “click” is heard.
ENEN
04 05
