1. COMPONENTS
CUP MASTER
A040.104.00
1
End apron
2x
Field support brace
2x
Red player
11x
Screw T3.5 x 25 mm
10x
Bumper
16x
Ball entry cup
2x
Screw #8 x 5/8”
8x
Bolt 1/4” x 1-3/4”
4x
Side apron
2x
5 player rod
2x
Bolt #8 x 32 mm
26x
Washer 5/16” x 23 mm
16x
Rubber end cap
8x
Ball return
2x
Goal door
2x
Plastic washer 5/8”
16x
Allen wrench
1x
Bolt 5/16” x 1”
8x
Bushing
4x
Playing field
1x
3 player rod
4x
Nut #8
26x
Drink holder
2x
Ball
4x
Slide scoring
2x
Screw #8 x 5/8”
2x
Leg
4x
2 player rod
2x
Screw T3.5 x 10 mm
20x
Rod handle
8x
Screw F4 x 2”
4x
Bolt 5/16” x 1-1/2”
8x
Leg leveler
4x
Leg panel
2x
Blue player
11x
Ball return tube
2x
Nut
8x
Bolt 1/4” x 2-1/4”
8x
Washer 1/4” x 19 mm
12x
6
11
16
21
26
31
36
7
12
17
22 23 24 25
27
32
37
8
13
18
28
33
38
9
14
19
29
34
39
10
15
20
30
35
2 3 4 5
