INSTALLATION + LOCATION
SWINGING DOOR
SEE PAGE 9 FOR REFERENCE TO:
Door Sensors
15
1/2” Max
Magnet
Contact
Sensor
CorrectCorrect Incorrect
1/2” apart and align the two semi-circles
