STEP 3
Fix the leg rest.
❶ Place the rear of leg rest near in front of massage chair.
❷ Pair the leg and foot harness plug with the socket on the main body and air tube plug on the main body.
❸ Raise the leg rest with both hands, push the shaft of leg rest toward the level pin of the hangers and lock it
to the main body.
❹ Paste the Velcro of the leg rest with the seat cushion.
INSTALLATION
Spindle
Limit Level Pin
Wiring
Harness Plug
Wiring
Harness Plug
Air Tube
Air Tube
❶
❷
❹
❺
❻
❸
Velcro of the front seat.
Velcro within the leg rest
connection leather.
Velcro of the front
seat cushion.
Velcro outside the leg
rest connection leather.
Note: The shaft must be securely attached, otherwise it will fall o. When inserting the air tube
plug and wiring harness, do not wrap the air pipe and wiring harness together.
12
