ZTR Model A191 Page 5
CHECK OPERATION OF SAFETY STOP SWITCHES
Seat Switch -
While sitting on stationary machine with Engine running
ENGAGE Cutter PTO Switch. Lift weight from Seat.
Engine should stop.
While sitting on stationary machine with Engine running
and Cutter PTO Switch in DISENGAGED position, set the
Park Brake Lever in the OFF position and then the Drive
Control Levers in the DRIVE position. Lift weight from
Seat.
Engine should stop.
Drive Control Lever Switches -
While sitting on stationary machine with Engine
running and Cutter PTO Switch in DISENGAGED
position and Park Brake Lever set in the ON
position attempt to move the Drive Control Levers
to the DRIVE position.
Engine should stop.
Park Brake Lever Switches -
While sitting on stationary machine with Engine
running and Cutter PTO Switch in DISENGAGED
position, and Drive Control Levers in DRIVE
position, attempt to set the Park Brake Lever in
the ON position.
Engine should stop.
To Next Page
