COZY III - Page 33

Cozy III
Pilot’s Operating Handbook Page 33
LIMITATIONS
Figure 4: Allowable Flight Envelope
PLACARDS:
Install these placards in the cockpit, visible to the pilot:
Min. Front Seat Weight (If less, add ballast) ____lbs.
Max. Front Seat Weight ____lbs.
Max. gear extension speed 120 kts. (138 mph)
Max. speed with gear down 150 kts. (172 mph)
No aerobatic maneuvers are approved except those listed below:
Maneuver Recommended Entry Speed*
Chandelles ..................................................... 130 kts (150 mph)
Lazy Eights .................................................... 130 kts (150 mph)
Steep Turns ................................................... 130 kts (150 mph)
Stalls (No whip stalls) ..................................... Slow deceleration
Accelerated Stall ............................................ 110 kts (126 mph)
*Abrupt use of controls prohibited above...... 120 kts. (140 mph)
