Table of Contents
Specifications 2
General Safety 3
Icon Library 4-5
First Time Start Up 6
Theory of Operation 7-8
Other Functions 9
Maintenance and Care 10-11
Parts List and Warranty 11
A/C Database End-User License Agreement 12-13
Unit Consists Of:
Specifications
• FX1234 Automotive Refrigerant Management Center
• Low and High side service hoses R-1234yf
• Low and High side R1234yf Service Couplings
• Tank Refill Adapter-Fits High side female for R-1234yf tank thread
• R-1234yf conversion fittings for hose storage and oil flush block
• 41 cubic Inch CPS filter drier (Replacement part number FX3030X)
• 1 lb (454 gram) check weight
• Operation manual
• 1 Roll 2.25” x 50” Thermal Paper
• Built-in Refrigerant Identifier (Not included with FX1234W, but an External Identifier is required for the FX1234W to operate)
End user to provide:
• Refrigerant oil and/or dye for injection system
• Refrigerant
2
FX1234 Specifications
Power 115vac. 60Hz, 15a; 10” 12 gauge power cord
Compressor 2/3 HP Twin Cylinder Oil-less
Vacuum Pump 6 CFM, single stage
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 120” barrier type
Refrigerant R1234yf
Storage Tank 50 lb DOT with processor controlled heat band
Display 7” Touch Screen with 256 color graphical display
Printer 22mm heat transfer graphical
Construction
Sheet metal frame adorned by injection and rotary molded plastic. Two handle bars, 4” front casters and 10” foam-filled rear tires
for exceptional maneuverability
