23
PARTS LIST
Ref. No. Part No. Description
1 747-05184 Blade Control
2 749-04680-0637 Upper Handle
3 710-0895 Screw, 1/4-15 x .750
4 749-04608A-0637 Lower Handle
5 720-0279 Wing Nut
6 710-1205 Rope Guide
7 710-04998 Carriage Screw ,5/16-18
8 710-04995 Screw, 5/16-14 x .750
9 720-04072A Hand Knob
10 731-07486 Side Chute
11 725-0157 Cable Tie
12 712-04222 Nut, Sq., 1/4-20
13 911-04143B Front Axle Assembly
14 747-0710A Hinge Pin
15 787-01779 Chute Deflector Bracket
16 911-04142 Rear Axle Assembly
17 734-04562 Wheel, 7 x 1.8
18 631-04486 Rear Baffle
19 710-05073 Screw, 1/4-20 x .500
20 787-01869-4043 Deck - 21”
21 987-02516 Hinged Mulch Plug Assembly
22 787-01818A-0637 Front Height Adjuster Plate
23 748-0376E Blade Adapter
24 942-0741A Mulching Blade
25 710-1044 Screw , 3/8-24 x 1.50
26 732-1014C Torsion Spring
27 738-04419A Sldr. Screw, .375 x .126 x 1/4-20
28 712-04217 Flange Lock Nut, 3/8-16
29 720-04130 Adjustment Lever Knob
30 720-04123 Wing Nut
31 736-0524B Blade Bell Support
32 712-04064 Nut, Flange Lock, 1/4-20
33 734-04563 Wheel, 8 x 1.8
34 946-0957 Control Cable
35 710-0654A TT Sems Screw, 3/8-16 x 1.0
36 731-07203 Trail shield
37 731-07078 Front Cover
38 10T802-3776-B1 Engine
Craftsman Mower — Model No. 247.38520
