28
PARTS LIST
Craftsman Engine Model No. 10T802-3776-B1 For Craftsman Mower Model No. 247.38520
Ref.
No.
Part No.
1 699650 Cylinder Assembly
2 399269 Kit-Bushing/Seal (Magneto Side)
3 299819s Seal-Oil (Magneto Side)
4 798264 Sump-Engine
5 790169 Head-Cylinder
7 698747 Gasket-Cylinder Head
8 791781 Breather Assembly
9 695890 Gasket-Breather
10 691666 Screw (Breather Assembly
11 691245 Tube-Breather
12 692218 Gasket-Crankcase
13 691640 Screw (Cylinder Head)
15 691680 Plug-Oil Drain
16 796217 Crankshaft
20 391483s Seal-Oil (PTO Side)
22 692551 Screw (Crankcase Cover/Sump)
23 795549 Flywheel
24 222698s Key-Flywheel
25 795691 Piston Assembly (Standard)
795689 Piston Assembly (.020” Oversize)
26 795690 Ring Set (Standard)
795688 Ring Set (.020” Oversize)
27 691588 Lock-Piston Pin
28 699659 Pin-Piston
29 699654 Rod-Connecting
32 691664 Screw (Connecting Rod)
33 296676 Valve-Exhaust
34 296677 Valve-Intake
35 690520 Spring-Valve (Intake)
36 690520 Spring-Valve (Exhaust)
37 793478 Guard-Flywheel (Muffler Side)
37A 697403 Guard-Flywheel (Carburetor Side)
40 692194 Retainer-Valve
Ref.
No.
Part No.
43 697799 Slinger-Governor/Oil
45 690762 Tappet-Valve
46 691998 Camshaft
48 793347 Short Block
50 699644 Manifold-Intake
50 792388A Manifold-Intake
51 792389 Gasket-Intake
54 691111 Screw (Intake Manifold)
55 692144 Housing-Rewind Starter
58 697316 Rope-Starter
60 281434s Grip-Starter Rope
65 690837 Screw (Rewind Starter)
73 699850 Screen-Rotating
78 692198 Screw (Flywheel Guard)
89 692348 Plug (Cylinder)
90 798758 Carburetor
97 697414 Shaft-Throttle
106 690901 Seat-Inlet
130 691190 Valve-Throttle
163 271139s Gasket-Air Cleaner
180 494406 Tank-Fuel
188 692198 Screw (Control Bracket)
190 691640 Screw (Fuel Tank) (5/16-18x1.79)
190A 691108 Screw (Fuel Tank) (1/4-20x.58)
202 698835 Link-Mechanical Governor
209 698719 Spring-Governor (Light Blue)
222 698725 Bracket-Control
227 697402 Lever-Governor Control
287 691002 Screw (Dipstick Tube)
300 394569s Muffler
304 697411 Housing-Blower
305 692198 Screw (Blower Housing)
332 690662 Nut (Flywheel)
