ASSEMBLY
The table and stand are shipped disassembled. To attach the two, please use
the following procedures.
1. Remove the stand assembly from the packaging carton. Assemble the stand
together. (See Fig.1)
2. Remove the work support from the packaging carton and place it on the
sanding belt base. (See Fig.2)
3. Attach the worktable to the disc sander. Insert the work table support bar in to
the support bar hole using the socket screw to tighten.
4. Check the machine to make sure that all screws and bolts are tightened
securely.
Fi
.1
Fig. 2
Fig. 3
5
