REPAIR PARTS
15 HP 42" TRACTOR -- MODEL NUMBER 917.257573
DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 142603 Transaxle 6sp Std Dana, 41 109070X
Model No. 4360-79 42 19131312
2 110422X Spring Return BrakeT/a Zinc 44 105706X
3 123666X Pulley Transaxle Alum 45 110812X
4 12000028 Ring Retainer# 5100-62 46 12000039
5 !21520X Strap Pnt Torque 30 Deg Blk 47 127783
6 17490512 ScrewThdrol 5/16-18 X 3/4Tyt 48 123789X
7 130802 Plate Pnt Rod Shift T/a (blk) 49 123205X
8 131679 Rod Shifter Blk (dana) 50 STD523715
10 STD561210 Pin Cotter 1/8 X 1 Cad 51 STD541437
11 105701X Washer Plate Shf 388 Sq Hole 52 STD541431
12 19151216 Washer 15/32 X 3/4 X 16ga 53 105710X
13 74550412 Bolt 1/4-28unf Gr w/Patch 55 105709X
14 STD55I 125 Washer Lock Hvy Helical 1/4 56 74760620
15 74780544 Bolt Fin Hex 5/16-18unc X 2-3/4 57 130801
18 STD523710 Bolt Fin Hex 3/8-16unc X 1 58 127274X
19 STD541437 Nut Lock 3/8-16 Unc 59 140312
20 17490512 Screw Thdrot 5/16-18 X 3/4Tyt 61 17490612
21 106933X Knob Rd 1/2-'13 PlstcThds BIk 62 8883R
22 130804 Rod Brake Lt 63 140186
24 STD541237 Nut Hex,Jam 3/8-t6 Unc 64 71170764
25 106888X Spring Rod Brake 2 00 Zinc 65 STD551143
26 STD55!037 Washer 13/32 X 13/16 X 16 Ga 66 129921
27 STD561210 Pin Cotter 1/8 X 3/4 Cad 70 134683
28 140448 Rod Brake Parking Lt 72 19132012
29 124236X Cap Parking Brake Red 74 109502X
30 130807 Bracket Transmission 75 121749X
31 127275X Keeper Belt Lh Lt 14 Ga 76 STD581075
32 STD523707 Bolt Fin Hex 3/8-16unc X 3/4 77 123583X
34 122424X ShaftAsm Pedal Foot 1 930 78 121748X
35 120183X Bearing Nylon Blk 629 td 100 19111216
36 STD551062 Washer 21/32 X 1 X 16 Ga I12 19091210
37 STD571810 Pin Rolt 3/16 X 1"
38 !23674X Pulley Idler Flat
39 STD523727 Bolt Fin Hex 3/8-16unc X 2-3/4
40 4470J Spacer Split 395 X 59 Bzp
Keeper Belt Retainer
Washer 13/32 X 13/t 6 X 12 Ga
Bearing Nyl 503 X 628 X 1 25
Washer Hardened
Ring Klip #t5304-50
Pulley idler V Groove Plastic
Beltcrank Asm
Retainer Belt Style Spring
Bolt Flex Hd 3/8d6unc X 1-1/2
Nut Crownlock 3/8-16 Unc
Nut Crown Lock 5/16-18
Link Clutch 7 66
Spring Return Clutch 6 75
Bolt Fin Hex 3/8-t6unc x 1-1/4
V-belt Ground Drive 95.25
Keeper Belt Rh Lt Pnt/zinc 16g
Retainer Belt Chassis Lh Zinc
Screw Thdrol 3/8-16x3/4 Ty4t
Cover Pedal BIk Std
Pulley Engine
Bolt Finhex 7/16-20 x 4 g5
Washer Lock Hvy Hlcl Spr 7/t6
Keeper Belt Engine Lh Lt
Guide Belt Dr Mower Rh
Washer 13/32 X 1-1/4 X 12 Ga
Spacer Split .80xl.94
Washer 25/32 X 1 1/4 X 16 Ga
Ring E #5133-75
Key Square 2 0 X 1845/1865
Washer 25/32 X '15/8 X 16ga
Washer 11/32 x 3/4 x 16 Gao
Washer 9/32 X 3/4 X t0 Ga
NOTE: All component dimensions given in USo inches
1 inch = 25°4 mm
