Alarm setting
Alarm 1 setting:
1. Make sure the unit is in power off (standby) mode before setting.
2. Press the VOL+ / AL 1 Button alarm 1 time will appear on the display and blinking.
3. Press the TUN- / MIN or TUN+ / HR Buttons to set minute and/or hour. (Make sure the PM
Indicator is light if the alarm time is PM and not light if the alarm time is AM).
4. When finished settings, press the VOL + / AL 1 Button to save the settings and exit.
5. Press the VOL + / AL 1 Button repeatedly to s
et the weak up mode to Buzzer or Radio as
desired. The correspondence indicators will light.
Alarm 2 setting:
Same as Alarm 1 set. But, press the VOL - / AL 2 Button instead of VOL + / AL 1 Button.
Note:
If radio wake up mode was selected, received the desired radio station and set volume level as
previous procedures before activate alarm. Otherwise, when Alarm goes off, no sound will heard
from the speaker.
Shut off alarm:
1. When alarm goes off, press the SOURCE / AL. OFF Button to turn o
ff alarm, the alarm will
reset for next day.
2. To turn off the alarm completely (not reset for next day). Press the VOL + / AL 1 or VOL - /
AL 2 Button repeatedly until correspondence indicators turned off.
Snooze:
The alarm can be temporarily turned off manually by pressing the SNOOZE/ SLEEP Button; the
alarm will turn back on automatically nine (9) minutes later. This feature can be repeated until the
SOURCE / AL.OFF Button was pressed.
Sleep Timer:
In the power on mode, press t
he SNOOZE / SLEEP Button to activate the sleep function (SLEEP
time will appear on the display). Press the SNOOZE / SLEEP Button repeatedly to set the sleep
timer to 10 – 90 minutes as desired. To turn off the sleep timer before time up, press the
SOURCE / AL.OFF Button.
8
TROUBLESHOOTING GUIDE
SYMPTOM POSSIBLE POSSIBLE SOLUTION
GENERAL
Power does not
come on.
AC/DC adaptor had
not plugged in
correctly
Insert the AC/DC Adaptor to the unit and AC wall
outlet correctly
RADIO
No sound.
Did not power on the
radio
Press the SOURCE/AL.OFF Button to power on
the radio Press the SOURCE/AL. OFF Button
repeatedly to selected AM or FM band as desire
Volume at minimum
position
Press the VOL + Button to rise volume level
Noise or sound
distorted on AM or
Alarm time not set Set alarm time
Clock not set Set the clock
SPECIFICATIONS
Frequency Range: AM 535 - 1710 kHz
FM 88 – 108 MHz
Power Source: DC
6V, 200mA
Clock Back-Up: DC
3V, 2 x AAA size batteries (Not included)
Audio Power: 0.3 W
Impendence of speaker: 8 Ohm, 0.5 W
Specifications are subject to change without prior notice.
Accessories:
1 x User’s Manual
1 x AC/DC Adaptor (Input: AC 120V~, 60Hz, 500mA; Output: DC
6V, 200mA
9
CRAIG CR45372 (40018) / IM (REAR) / COLOUR: GRAYSCALE / SIZE: W290 x H210 (MM) / Scale 1:1 / DATE: 22 NOVEMBER 2012
Craig warrants this product to be free from manufacturing defects in material and
workmanship under normal use for a period of 90 days from date of purchase. If service
is required, please return the product to the store where it was purchased for exchange;
or, pack the unit in the original packing material with all accessories if applicable, a copy
of your sales receipt and a Cashier’s check or Money Order for $3.00 (to cover shipping
and handling costs) payable to Craig Elec
tronics Inc. For consumers in Canada, please
make sure that the cashier check or money order is redeemable through a U.S. bank.
Ship your product freight pre-paid. Your unit will be repaired, replaced or if the unit can
not be repaired or replaced, a refund will be forwarded to you within four weeks of receipt
of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a commercial applica
tion or
rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d) Damaged because it is
improperly connected to any other equipment.
Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s
Manual which can be performed by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the product for repair. d)
Damag
e to the product not used in the USA.
This warranty is not transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantability, are limited in duration to the period
of this expressed warranty and no warranty whether expressed or implied shall apply to
the product thereafter.
Under no circumstance shall Craig be liable for any loss or consequential damage arising
out of the use of this product. This warranty gives speci
fic legal rights. However, you may
have other rights which may vary from state to state. Some states do not allow limitations
on implied warranties or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China CR45372-IB-E0CH1-B0US
