3254 - 2-56 Button Head
4019 - Alum Pivot ball
12772 -
4-40 Thin
Hex Nut
1429 -
4-40 x 7/16”
Flat Head
1209 - Washer
*Note - Sometimes it is helpful to over-tighten the top clamp screws,
then work the ball around by hand, and then loosen the screws so the ball
floats around very free. Do not over-tighten the screws too much or you
could warp the pivot socket.
slightly
1412 - Red Locknut
Bag 1
Center Pivot
1
3374 - Center Pivot Socket
Bag 1
Center Pivot
1957 - BA3.0 Chassis Plate
3374
1957
To Next Page
