Once
you
have
established
that
the
Long
Driver
Board
is
good
then
move
on
to
the
light
box,
see
chart
-
pages
5-067
and
5-081,
also
5-074.
Determine
exactly
which
bit
is
the
one
to
control
the
light
and
find
the
corresponding
number
in
the
light
box
and
the
Light
Module
board
that
controls
it.
( Be
careful
not
to
touch
or
brush
up
against
the
A.
C.
voltage).
Jumper
the
red
terminal
#3
to
a
good
ground
to
be
located
on
the
chassis
or
box.
You
should
read
25
volts
on
that
test
point.
If
you
do
not
have
that
voltage
on
the
CEI
1
Board,
then
the
cable
is
possibly
bad,
exchange
it
for
another
cable.
If
that
is
the
problem
then
repair
or
replace
it.
On
the
inside
left
hand
side
of
the
light
box,
find
the
correct
terminal
in
the
white
set
of
terminals
and
jumper
this
terminal
with
the
matching
one
in
the
yellow
set
of
terminals.
(Be
extremely
careful
--
Be
sure
the
jumper
is
insulated
DO
NOT
TOUCH
the
exposed
lead,
bare
wire
or
terminal.
This
is
live
A.
C.
110
volts!
)
If
that
turns
the
light
on,
then
replace
the
CEI
1
board
and
triac
with
one
of
the
spare
ones
at
the
bottom
right
hand
corner
of
the
box.
Be
sure
you
shut
off
the
whole
box
before
you
replace
the
Module.
CC
Panel
8
Triac
or
20
Triac
Boxes
)
Take
a
reading
on
the
110
volt
A.C.
line
to
see
if
you
have
the
power
to
the
box.
You
can
read
the
voltage
with
a
probe
at
the
negative
lead
at
the
1000
mfd.
cap.
on
the
power
supply.
The
positive
side
can
be
read
from
the
black
wire
of
the
A.C.
input.
Caution,
live
110
volts
in
the
Triac
box.
See
the
circuit
layout
drawing
for
8
or
20
Triac
Driver
boxes
of
detailed
information,
see
pages
5-065
and
5-071.
Houselight
Problems
Check
the
override
switch
and
see
if
it
has
been
switched
to
override
by
mistake.
If
so,
return
it
to
the
correct
position.
Verify
the
background
music
mute
by
hitting
a
manual
stop
and
then
play
again
and
see
it
the
background
music
turns
off
and
on
correctly.
If
the
background
music
mutes,
but
the
lights
do
not
dim,
then
replace
Q3.
If
the
background
music
doesn't
mute
then
replace
the
Show
Control
Board.
A.C.
Monitor
-
Check
the
A.
C.
Monitor
output
on
pin
#5.
You
should
read
12.5v.
A.
C.
at
120hz.
with
a
positive
going
pulse
waveform,
see
pages
5-063
and
5-064,
also
5-068
and
5-076.
If
you
do
not
have
this,
then
trace
the
A. c.
signal
back
through
the
Dual
P.
C.
Mount,
cable
and
Tunnel,
and
out
the
rear
of
the
cabinet.
Unplug
the
molex
cable
from
the
J13
Interface
at
the
rear
of
the
cabinet,
(
red
and
white
wire),
and
check
for
A.
c.
voltage,
on
the
cable.
Next,
unplug
the
same
cable
at
the
A.
C.
monitor
box
and
check
the
output
of
the
monitor,
see
schematics
and
drawings
on
pages
5-063
and
5-064,
also
5-068
and
5-076.
Houselight
Dimmer
Board
-
If
the
Houselights
are
in
the
dim
position
try
to
adjust
the
'Pots'
on
the
board
see
schematic,
page
5-063
and
5-064.
Set
VR2
counter-clockwise
all
the
way
and
VR3.
counter-clockwise
all
the
way.
Set
VRl
to
minimum
light
level
