* CABLES*
* *
*********
CABLES
1. Cable #1 (Rolfe & B.Bob) *
a. 25'
b. SO'
2. Cable #2 (Dook & B.Bear)*
a. 28'
b. 40'
3. Cable #3 (Fatz)
4. Cable #4 (Mitzi)
5. Cable #5 (Props)
6. Cables #7 (Looney Bird)
7. Cable (Organ and Sign)
8. Cable adapter
(Y-cable organ and sign)
9. Cable #9 (curtain #1-old style)
10. Cable #10 (curtain #2-old style)
11. Cable #11 (curtain #3-old style)
12. J-13 Interface Cable
13. AC monitor cable
14. Stage/floods control box cable
15. Manager control cable
16. Spots cable (RAF 100 panel only)
CC PANEL CABLES
17. Cable #1~ (Spotlight and curtain
output)
18. Cable #14 (Floodlights)
19. Cable #15 (Stage)
El8-10200
El8-10210
El8-10240
El8-10250
El8-10220
El8-10230
El8-10270
El8-10260
ElS-10340
El8-10350
El8-10280
El8-10290
ElS-10300
El7-10220
El7-10400
E9-604
El8-10900
E9-504
El8-10330
El8-10360
El8-10370
* Length determined by distance to control room
5-073
