10 Live! Drive IR Quick Start SB0010
Step 4: (Optional)
Install the Digital DIN
Metal Bracket
(To connect to FPS2000,
DTT2500 or DTT3500
digital speakers)
1. Remove the metal plate from a vacant ISA or PCI expansion slot.
2. Align the Digital DIN metal bracket with the vacant expansion slot opening.
3. Secure the metal bracket to the system casing with a screw.
Step 5: (Optional)
Connect to the
Digital I/O Card
(Only if you have one)
Connect the light grey flat cable to the Digital I/O card’s AUD_EXT header.
If you have difficulty connecting to the AUD_EXT header:
1. Remove the Digital I/O card from the system.
2. Connect the light grey flat cable to the Digital I/O card.
3. Place the metal bracket of the Digital I/O card into the vacant bracket on the system casing.
4. Secure the card to the system casing with a screw.
Step 6:
Complete the Installation
1. Connect the power splitter cable to the system power supply unit.
2. Replace the cover onto your system.
3. Plug the power cord back into the wall outlet, and switch on the system.
