INSTALLATION
6
Fig. 1
The area marked must be clear of obstructions including the wall switch, mains cable
and main cable socket outlet because of the position of oven vents and hob.
225mm
650mm
Side Wall to be no
closer than 150mm
Side Wall to be no
closer than 150mm
650mm
900mm
CABINET
(front)
CABINET
(front)
250mm
250mm
550mm
75
