Creda D900E - Page 10

10
Using Your Hob
Creda Hob Units - Features
Model No. D900E
Heating Areas:
(1) 1.2kW
(2) 1.8kW
(3) 1.2kW
(4) 1.8kW
230 - 240V
˜
5.5 - 6.0 kW
50Hz
1
2
3
4
The control panel has been marked to identify each control knob with the appropriate cooking
area. Some models have ‘hob on’ indicator lamps on the controls.These illuminate
when the appropriate control is switched on.
The knobs can be rotated in either direction to provide fully variable heat control.
All models also have a hob hot warning light, to indicate when any heating area may be
hot.This illuminates when any control is switched on and remains illuminated for some time after
switching the control off.
2 1
4
3
Credaplan
Model No. 42356 MK2 (Green) 240V
42356 (Green) 240V
42357 (White) 240V
42387 (Blue) 240V
Heating Areas:
(1) 1.2kW
(2) 1.8kW
(3) 1.2kW Solarglo
(4) 1.8kW Solarglo
With brass knobs.
230 - 240V
˜
5.5 - 6.0 kW
50Hz
1
2
3
4
2 1
4
3
The rating plate for all models is situated on the underside of the base panel.
