Regulators repair and maintenance

stage Ellipse Balanced:

disassembling

January 2009 Rev. ELL.BAL/B Ed. C /12 27

• Remove the nozzle out of the regulator valve body using the tool HZ 709011 (designed to

prevent the edge from being damaged) as shown in the picture;

• NOTE: push with a certain amount of strength to overcome the friction induced by the O-

ring onto the valve body side, until the nozzle comes out.

• Remove the nozzle O-ring.

HZ 810094

HZ 709011
