Regulators repair and maintenance
January 2008 Rev. ELL. OCTO /A Ed. B / 09 29
2nd stage ELLIPSE Black
Connect the valve with the regulator and insert the previously removed pad back
into the valve shaft bush.
Note: use the old pad in order to prevent the fresh one to be damaged by the
nozzle cutting edge, as will be seen later.
Assembling the 2nd stage mechanism
HZ 742013
