SP / TC / GT
APPENDIX A
CENTURY SERIES
Side Dimensions The following diagram illustrates the depth and height dimen- sions (from the side) for all Century SP / TC / GT consoles.
2.25"/57mm
KNOB HEIGHT 0.75"/19mm & 1.25"/32mm
24.75"/ 717mm
28.0"/ 711mm
29.563" / 751mm
29.625"/752mm
10.25"/260mm
6.25"/159mm
3.25"/83mm
9.5"
241mm
2.437" 62mm
1.125"/29mm
2.375"/60mm
35°
All information per
Crest Consoles Engineering,
May 5, 1997
