SP / TC / GT
APPENDIX C
CENTURY SERIES
Appendix C - Schematics
LOCATION DESCRIPTION SCHEMATIC # DWG # REV #
STANDARD INPUT MODULE INPUT CONNECTOR PCB 1 N/A 04
GT INPUT MAIN PCB 2 76D1530 04
TC INPUT MAIN PCB 3 N/A 02
SP INPUT MAIN PCB 4 N/A 02
STEREO INPUT MODULE STEREO INPUT CONNECTOR 5 76D1920 02
STEREO INPUT
MAIN PCB (1 OF 2) 6 76D1919 01
STEREO INPUT
MAIN PCB (2 OF 2) 7 76D1919 01
GROUP MODULE GROUP CONNECTOR PCB 8 N/A 01
GROUP MAIN PCB 9 N/A 03
LEFT / RIGHT
OUTPUT MODULE LEFT / RIGHT CONNECTOR PCB 10 N/A 01
L/R MAIN PCB 11 N/A 04
MONO OUTPUT
MODULE MONO CONNECTOR PCB 12 N/A 04
MONO MAIN PCB 13 N/A 03
MASTER CONTROL
MODULE MASTER CONNECTOR PCB 14 N/A 04
MASTER MAIN PCB 15 N/A 04
MATRIX MODULE MATRIX CONNECTOR PCB 16 76D1922 02
MATRIX MAIN PCB 17 76D1921 01
RIBBON CABLE
PIN OUT DIAGRAMS RIBBON PIN OUTS 18
GT
TC
SP
