4
C10H-C15H
W2H
W3.5H
The
W2H, W2HT, W3.5H, C10H-C15H
have been designed for your safety when working at
height. They have a unique sealed braking sytem that ensures the device pays out freely but
locks on rapidly to minimise free fall and impact loads on both the anchorage and the body.
If the unit has been deployed, the hook load indicator will show on the swivel hook (W3.5H,
and C10H-C15H only). The W2H and W2HT has a load indicator built into the top swivel that will
display a red band when activated. If this is visible DO NOT USE.
Introduction to
Fall Arrest Blocks & Scope off Use
W2H - 2m (6ft) max working length.
W2HT - Twinlock, 2x2m (6ft) max working length.
W3.5H - 3.5m (10ft) max working length.
C10H - 10m (33ft) max. working length.
C15H - 15m (49ft) max. working length.
Max user weight 140 kg when working vertically.
Max user weight 100 kg when the block is mounted
between foot level and head height (horizontal use).
Sleek and modern design.
Anchorage karabiner as standard.
Top swivel on all models.
Range of alternative karabiners.
Light weight (inc swivel hook)
W2H - Webbing <0.7Kg.
W2HT - Webbing <1.5Kg.
W3.5H - Webbing <1.1Kg.
C10H - Wire Rope <4.1Kg.
C15H - Wire Rope <6.5Kg.
Composite housings UV stabilised.
Internal steel chassis.
Alloy swivel hook as standard.
Sealed Braking System (C10H, C15H only)
Cleaning brushes to reduce debris entering the unit. (C10H, C15H only)
Fully serviceable (C10H, C15H only)
Tested for vertical and horizonal use.
Reference to testing to CNB/P/11.060 Type A
The W2H has also been tested and approved for anchorage at foot level.
Reference to testing to CNB/P/11.085
