Troubleshooting
The following table provides corrective actions for possible troubleshooting situations. If
further assistance is required, contact a Crestron customer service representative.
DIN-AP3 Troubleshooting Table
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
The device does not
function.
The device is not
communicating with the
network.
Use Crestron Toolbox to
poll the network. Verify
that the network is
connected to the device.
The device is not
receiving power from a
Crestron power supply.
Use the provided
Crestron power supply.
Verify that the
connections are correct
and secure.
The device is not
receiving sufcient
power.
Use the Cresnet Power
Calculator to help
calculate how much
power is needed.
The MSG LED
illuminates.
There is a hardware or
software failure.
Verify that the hardware
conguration matches
the software
conguration. Use
Crestron Toolbox to
display the error log.
The compilation error
RLCMCVT166 or
RLCMCVT177 appears.
A poor analog versus
signal denition exists in
the SIMPL Windows
program.
Conrm that the signal
denition is properly
dened in the program.
The system locks up. There are various
causes.
Hold down the SW-R
button on the control
system front panel to
bypass the program and
to communicate directly
with the processor. Refer
to "Troubleshooting
Communications" in the
3-Series Control System
Reference Guide
(Doc. 7150) at
www.crestron.com/
manuals for more details.
A Cresnet device does
not respond.
The device is not wired
correctly.
Verify that the Cresnet
wiring is correct and
secure.
An improper NET ID was
used.
Verify that the device ID
matches the NET ID in
the program.
There is a loss of
functionality due to
electrostatic discharge.
The device is improperly
grounded.
Check that all ground
connections have been
properly made.
DIN-AP3 Troubleshooting Table (continued)
The A/V system device
does not respond.
The IRP2 or the serial
port is not placed
properly.
Verify the placement of
the IRP2 (hold the
phosphor card under the
IRP2 while pressing the
button), and tighten the
serial cables.
The wrong IR/serial port
was used.
Verify that the proper
IR/serial port is dened.
The serial cable is not
wired correctly.
Verify that the serial
cable is wired correctly
for RS-232/-422/-485.
The device is not
receiving sufcient
power.
Use the Cresnet Power
Calculator to help
calculate how much
power is needed.
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION

Crestron DIN-AP3 Specifications

General

Internal memory	0.256 GB
Storage media type	Flash
Internal memory type	DDR3 SDRAM
Internal storage capacity	4 GB
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
RS-232 ports	2
AC input voltage	24 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Heat dissipation	26 BTU/h

Weight and Dimensions

Depth	59 mm
Width	160 mm
Height	95 mm
Weight	277 g
