CROSS-RC Demon SR4C - Page 9

M3x4
11401
M3x8
11106
1
THREAD
LOCK
11401
41293
11106
32704
17009
200203
32703
95028
11130
11130
M2x20
2
NOTE:
Get power test after assembly finish and adjust
gear meshing clearance for make sure gear box running
smooth without noise,then process to following
assembly go on.
3
11116
M2.5x12
11116
200201
32701
200202
32702
∅5x∅11x4
15006
∅5x∅8x0.3/∅5x∅8x0.3
72007/72026
41292
72007
72026
15006
72007
72026
15006
9
THREAD
LOCK
16mm
MAX
17mm
THREAD
LOCK
