CFQ5.2 front panel
1. Input select button: selects from input 1 to input 2
2. Peak indicator: this will illuminate when the inputs or outputs are overloaded
3. Power on/off indicator: this illuminates when system is turned on
4. Master volume control: used to control the system volume when the source unit is preset to a specific
volume.
5. Fader: adjusts the proportionate level of the front and rear outputs
6. Subwoofer level control: adjusts the subwoofer output level below the crossover frequency selected.
7. 50 Hz: this adjusts the boost or cut of up to 12 dB at 50Hz.
8. 250 Hz: this adjusts the boost or cut of up to 12 dB at 250Hz.
9. 1 KHz: this adjusts the boost or cut of up to 12 dB at 1KHz.
10. 2.5 KHz: this adjusts the boost or cut of up to 12 dB at 2.5KHz.
11. 6.5 KHz: this adjusts the boost or cut of up to 12 dB starting at 6.5KHz and peaking at 22KHz
CFQ5.2 rear panel
1. Subwoofer output: accepts male RCA connectors leading to the subwoofer amplifier
2. Rear output: accepts male RCA connectors leading to the rear speaker amplifier
3. Front output: accepts male RCA connectors leading to the front speaker amplifier
4. Input 2: pigtails accept male RCA connectors from an auxiliary source
5. Input 1: pigtails accept male RCA connectors from primary source
6. Input 2 level control: use flathead screw driver to adjust the input level to match that of the primary
unit’s (source) input.
7. Input 1 level control: use a flathead screwdriver to adjust the input level to the source unit’s output .
8. 4 pin modular socket: contains the power, ground and remote turn-on input and delayed remote
output.
