CROSSRC MC8B - Page 15

NOTE:
Get power test after assembly finish and
adjust gear meshing clearance for make sure gear
box running smooth without noise,then process to
following assembly go on.
1st Gear
(Low speed)
2nd Gear
(Hight speed)
M3x8
11303
THREAD
LOCK
11303
11303
44016
44016
THREAD
LOCK
14
95042
M3x10
11409
95043
M3x10
11402
95043
(95042)
11402
(11409)
MC8B/C
MC8B/C
95019
(95041)
MC8B
MC8C
11402
(11409)
THREAD
LOCK
THREAD
LOCK
95041
95019
