Lighting System
MC8B/C
J5
5mmLED
Right turn signal
(yellow)
J1
5mmLED
Headlamps
(white)
J2
5mmLED
Cab light
(yellow)
J8
5mmLED
Left turn signal
(yellow)
J1
5mmLED
Headlamps
(white)
J9
5mmLED
Left turn signal
(Yellow)
J13/J14
5mmLED
Reversing light
(white)
J6
5mmLED
Right turn signal
(yellow)
J13/J14
5mmLED
Reversing light
(white)
J11/J12
5mmLED
Brake light
(Red)
J11/J12
5mmLED
Brake light
(Red)
