CROSSRC SP4C - Page 11

M3x4
11401
M3x8
11106
THREAD
LOCK
11401
41293
11106
32704
17009
SP4A:200203
SP4B/C:32703
95028
11130
11130
M2x20
NOTE:
Get power test after assembly finish and adjust
gear meshing clearance for make sure gear box running
smooth without noise,then process to following
assembly go on.
11116
M2.5x12
11116
SP4A:200201
SP4B/C:32701
SP4A:200202
SP4B/C:32702
∅5x∅11x4
15006
41292
SP4A:72026
SP4B/C:72007
15006
72007
72026
15006
THREAD
LOCK
16mm
MAX
17mm
1
2
3
∅5x∅8x0.3/∅5x∅8x0.2
72007 / 72026
11
THREAD
LOCK
SP4(A)/(B)/(C)
SP4(A)/(B)/(C)
BAG(D)
BAG(C)
