19 20
MAINTENANCEMAINTENANCE
When the charger is working for the batter-
ies. please don't disconnect the output cord
from the battery receptacle, which may
cause spark and charging abnormal.
1.The charger will turn off automatically when
the batteries are full charged.
2.After the charger has turned off disconnect
the AC output plug from the golf car recep-
tacle by grasping the plug body and pulling
the pulg straight out of the receptacle.
1.Place the car on a horizontal level
2.Open the cushion
3.Open the tank filler cap
4.pour the oil (model:GL-4 75W/90) in
the gearoil slowly until it reachs the oil
overflow valv.
5.It’s fine for oil overflowing。Make it
stop when it flows out
6.Screw back the cap.
Recommended oil：
SAE 90 gearoil
Gearcase capacity：
0.3L
WARNING
Other materials are forbidden from getting
into the gearbox
CAUTION
When installing the batteries,do not put the
wrenches or other metal objects across the
battery terminals. High current sparks
could lead to causing explosion of the
batteries.
WARNING
Check the oil level in the gearbox
Gearbox oil
BATTERY INSTALLATION
For oil changement,please consult your
Lvtong dealer or other qualified mechanic.
NOTE:
