Installation
6-1
Section 6: Installation
6.1 Reliquefier installation
The entire section on the reliquefier installation should be reviewed before installing the
reliquefier.
CAUTION
Operating the Reliquefier in a magnetic field of greater than 500 gauss will void the
warranty.
CAUTION
The Liquid Helium Return Line extending out of the side of the Helium Re-liquefier
Main Assembly is extremely delicate. Please handle with care. Do not bend or
adjust without contacting Cryomech. The line is vacuum jacketed and constructed
of very thin walled stainless steel tubing with very close tolerances.
6.1.1 Inspect the Reliquefier
Figure 6-1: Representative schematic of a Reliquefier
