CTE PRO Series - Page 8

SERVICE
MANUAL
6
5
2
3
7
1
4
8
MAIN PARTS PLATFORM
9
10
11
12
1 Ground main controls
2 Stabilizers controls
3 stabilizer
4 Angle sensor inside arm
5 arm
6 Basket main controls
7 basket
8 Cover protection valves
9 Basket rotation motor
10 Pressure transducer
11 Stabilizers block valve
12 Rotatation assembly
