14 se c t i O n 6— Ma i n t e n a n c e & ad j u s t M e n t s
Replacing Rear Flap
To remove rear flap, lift rear door, and press flap in on 1.
either side to remove from hole. See Fig. 6-2.
Remove flap from opposite hole and replace with new flap 2.
in the opposite order and manner of removal.
Adjustments
Drive Cable
Your unit is equipped with an adjustable drive cable to adjust
the tension on the drive cable. You will need to adjust the drive
cable if the mower does not propel itself with the drive control
engaged or if the mower’s wheels hesitate with the drive control
engaged. If either of these conditions occur, rotate adjuster
barrel - making it longer will give more drive and shortening
it will give less. This will also increase or decrease the force
required to engage the drive control. See Fig. 6-3.
