Cub Cadet CC 760 ES Illustrated Parts Manual

13
Tecumseh Transmission
Ref.
No.
Part No. Description
1 TC-772147 Transaxle Cover
2 TC-780086A Needle Bearing (¹/₂” long)
3 TC-770128A Transaxle Case
4 TC-776395 Countershaft
5 TC-776409 Output Shaft
6 TC-778364 Spur Gear (38T-PM/SER)
6A TC-778369 Spur Gear (15T-PM/SER)
7 TC-778330 Spur Gear (11T-PM/SER)
8 TC-792180A Shift Key Set (Qty. 2)
9 TC-784352 Shift Collar
10 TC-784378 Shift Rod & Fork Assembly
11 TC-778334 Bevel Gear (30T-PM)
12 TC-778309 Input Bevel Pinion (13T-PM)
13 TC-778368 Bevel Gear 13T (Incl. ref. 13 & 14)
14 TC-778368 Bevel Gear 13T (Incl. ref. 13 & 14)
15 TC-778370 Ring Gear (43T)
17 TC-786188 Drive Pin
18 TC-786102 Spacer (1.130” x .695”)
20 TC-792077A Ball (Stainless Steel ⁵/₁₆” dia.)
21 TC-792211 Screw, ³/₈-16 x ³/₈”
22 TC-792079 Spring
25 TC-792073A Screw, ¹/₄-20 x 1-¹/₄”
25A TC-792177 Screw, ¹/₄-20 x 1-³/₈”
26 TC-792125 Retaining Ring-package of 2
27 TC-792035 Retaining Ring
28 TC-788040 Retaining Ring
29 TC-780072 Washer .627” ID .031”
29A TC-780160 Thrust Washer (.563” ID x .031”)
29B TC-780051 Thrust Washer (.762” ID X .031”)
30 TC-780108 Shift Washer (Cupped)
31 TC-780001 Washer .750” ID .56”
31A TC-780195 Washer .750” ID .062
32 TC-788083 Oil Seal ⁵/₈”
32A TC-792001 O Ring (.823” OD)
34 TC-780194 Bushing (.563”)
35 TC-780193 Flanged Bushing (.625” ID)
35A TC-780197 Flanged Bushing (.751” ID)
Ref.
No.
Part No. Description
36 TC-790075 Brake Disk
37 TC-790007 Brake Pad Plate
38 TC-799021A Brake Pad (pkg. of 2)
39 TC-786026 Dowel Pin .3125” x .750”
40 TC-792076A Washer .312” ID .059”
41 TC-790104 Brake Lever
42 TC-792177 Screw ¹/₄-20 x 1-³/₈”
43 TC-792075 Lock Nut ⁵/₁₆-24
44 TC-790025 Brake Pad Holder
46 TC-786086 Bracket
47 TC-775146 Axle (10.719” long) (Incl. 26)
48 TC-775147 Axle (15.312” long) (Incl. 26)
49 TC-778338 Spur Gear (27T-PM/IC)
50 TC-778342 Spur Gear (22T-PM/IC)
51 TC-778313 Spur Gear (19T-PM/IC)
52 TC-778350 Spur Gear (16T-PM/IC)
56 TC-778337 Spur Gear (13T-PM/SER)
57 TC-778341 Spur Gear (18T-PM/SER)
58 TC-778351 Spur Gear (21T-PM/SER)
59 TC-778349 Spur Gear (24T-PM/SER)
63 TC-786071 Countershaft Spacer 1-¹/₈” x ³/₈’’
64 TC-786072 Brake Shaft Spacer 1-³/₈” x ³/₈’’
65 TC-780189 Washer .563” ID .062
66 TC-776472 Input Shaft
67 TC-776396 Brake Shaft
69 TC-792170 Retaining Ring (.75” x .042”)
70 TC-786187 Spacer (.890”)
71B TC-788092 O-Ring
76 TC-780090 Flat Washer (1.128” ID x .058”)
77 TC-788078A Retaining Ring (1.125” x .050”)
79 TC-792144 Spring
82 TC-778333 Bevel (30T) & Spur Gear
83 TC-778338 Spur Gear (27T-PM/IC)
85 TC-792154 Oil Fill Plug
87 TC-788089A Oil Seal ⁹/₁₆” ID
157 TC-788088A Oil Seal ³/₄” ID

Cub Cadet CC 760 ES Specifications

General

Drive System	Self-Propelled
Drive Control	Variable Speed
Deck Material	Steel
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Wheel Size (Front)	8 inches
Start Type	Recoil
Cutting Height Range	1.5 to 3.5 inches
