Cub Cadet CC 760 ES Illustrated Parts Manual

19
Briggs & Stratton Engine Model 215807
Ref. Part No. Description
311 BS-497608 Brush Set
324 BS-796308 Screen/Cup Assembly
333 BS-795315 Armature-Magneto
334 BS-691061 Screw (Magneto Armature)
337 BS-491055s Plug-Spark
356 BS-398808 Wire-Stop
358 BS-796181 Gasket Set-Engine
359 BS-691077 Washer (Ground Terminal)
373 BS-691612 Nut (Ground Terminal)
404 BS-691691 Washer (Governor Crank)
415 BS-794129 Plug (Rotating Screen)
431 BS-697122 Elbow-Intake
445 BS-698413 Filter-Air Cleaner Cartridge
474 BS-696578 Alternator
505 BS-691251 Nut (Governor Control Lever)
507 BS-691972 Insulator
510 BS-693699 Drive-Starter
513 BS-692024 Clutch-Drive
520 BS-691084 Terminal-Ground
521 BS-690581 Shield-Cable
523 BS-699908 Dipstick
524 BS-691032 Seal-Dipstick Tube
525 BS-697184 Tube-Dipstick
544 Armature-Starter
552 BS-697144 Bushing-Governor Crank
562 B S - 6 91119 Bolt (Governor Control Lever)
579 BS-691029 Nut (Starter Cable)
584 BS-794682 Cover-Breather Passage
597 BS-691696 Screw (Pawl Friction Plate)
601 BS-791850 Hose-Clamp (Green)
613 BS-691416 Screw (Muer) (5/16x4.1)
613A BS-691678 Screw (Muer) (5/16x.625)
614 BS-691620 Pin-Cotter (Governor Crank)
616 BS-692012 Crank-Governor
617 BS- 692138 Seal-O Ring (Intake Manifold) (Red)
621 BS-692310 Switch-Stop
633 BS-699813 Seal-Choke/Throttle Shaft (Choke Shaft)
634 BS-698779 Spring/Seal Assembly (Choke Shaft)
635 BS-691909 Boot-Spark Plug
643 BS-697155 Retainer-Air Filter
654 BS-690958 Nut (Carburetor)
691 BS-692407 Seal-Governor Shaft
Ref. Part No. Description
697 BS-690372 Screw (Drive Cap)
718 BS-690959 Pin-Locating
729 BS-691224 Clip-Wire
741 BS-697128 Gear-Timing
773 BS-796448 Retainer
783 BS-693713 Gear-Pinion
797 BS-693167 Nut (Brush Retainer)
801 BS-691283 Cap-Drive
802 BS-691286 Cap-End
803 Housing-Starter
823 BS-698941 Screw (Muer Adapter)
830 BS-691095 Stud-Rocker Arm
842 BS-691031 Seal-O Ring (Dipstick Tube)
847 BS-790442 Dipstick/Tube Assembly
850 BS-100106 Sealant-Liquid
851 BS-692424 Terminal-Spark Plug
864 BS-796002 Adapter-Muer
868 BS-690968 Seal-Valve
883 BS-692236 Gasket-Exhaust
914 B S - 6 9110 8 Screw (Rocker Cover)
967 BS-697292 Filter-Pre Cleaner
968 BS- 697420 Cover-Air Cleaner
975 BS-698783 Bowl-Float
987 BS-698777 Seal-Throttle Shaft
1005 BS-796082 Fan-Flywheel
1022 BS-272475s Gasket-Rocker Cover
1023 BS-797421 Cover-Rocker
1026 BS-794573 Rod-Push (Exhaust)
BS-697394 Rod-Push (Intake)
1029 BS -691751 Arm-Rocker
1034 BS-690822 Guide-Push Rod
1036
Label-Emissions (Available from a Briggs
& Stratton Authorized Dealer)
1040 BS-697381 Plate-Trim
1044 BS- 698139 Screw (Flywheel)
1051 BS-691265 Ring-Retaining
1058 BS-276344 Operator’s Manual
1059 BS-698516 Kit-Screw/Washer (Alternator)
1090 BS-691293 Retainer-Brush
1091 BS-691333 Cap-Limiter
1095 BS-795807 Gasket Set-Valve
1119 B S - 6 9118 3 Screw (Alternator)
