Cub Cadet CC 760 ES Illustrated Parts Manual

5
Drive and Deck
Ref.
Part Number Description
1 178 40 Transaxle Mounting Bracket
2 918-04639 4 Speed Drive Assembly, Tecumseh
3 710 -0176 Hex Head Cap Screw, 5/16-18 x 2.75
4 710-0347 Hex Head Cap Screw, 3/8-16 x 1.75
5 710-0376 Hex Head Cap Screw, 5/16-18 x 1.00
6 710-04187 Screw, 1/4-15 x 0.50
7 710-04377 Hex Head Cap Screw, 7/16-20 x 2.75
8 710 -0513 Hex Head Cap Screw, 1/4-28 x .625
9 710-0520 Hex Head Cap Screw, 3/8-16 x 1.50
10 710-3008 Hex Head Cap Screw, 5/16-18 x .75
11 710 -3015 Hex Head Cap Screw, 1/4-20 x .75
12 911-1000 Belt Keeper, .25 DIA X 3.0
13 712- 04063 Flangelock Nut, 5/16-18
14 712- 04064 Flangelock Nut, 1/4-20
15 712- 04065 Flangelock Nut, 3/8-16
16 712-0700 Flange Nut, 9/16-18
17 914-0145 Click Pin, .092 x 1.64 LG
18 718-04407 Spline Pulley Hub, 5/8
19 720-0142 Grip, Black
20 731-05766 Trailshield, 8.35 x 19.17
21 732-04409 Extension Spring, Wheel Drive
22 732-04443A Extension Spring, Brake
23 736-0105 Washer, Spring, .401 x .870 x .063
24 736-0270 Washer, Bell, .265 x .75 x .062
25 736-0322 Washer, Flat, .450 x 1.250 x .164
26 736-04256 Washer, Flat, .39 x .87 x .06
27 918-04438B Drive Spindle Assembly
28 738-04166 Spacer, Shoulder, .5000 x .1475
29 747-04635A Belt Keeper Rod
30 747-04673 Coupling Link, .188
31 747-04678A Brake Spring Mounting Rod
32 954-04145A V Belt. 4L 64.2
33 756-04129B Idler Pulley, 4.25 DIA
34 756-04258 Flat Sheave, DIA 7.75
35 756-04260 Engine Pulley, 3.20 x 4.35 DIA
36 756-04280 Idler Pulley, 3.50 DIA
37 787-01469B Lower Shaft Lever
Ref.
Part Number Description
38 787-01470A Upper Shaft Lever
39 787-01473 Belt Keeper, .375 x 2.00
40 787-01523A Wheel Drive Idler Bracket
41 918-04439B Spacer Spindle Assembly
42 931-04244 Chute Deector Assembly
43 631-04252 Mulch Cover
44 987-02420 Idler Arm Assembly
45 687-02476 Deck Assembly
46 710-04484 Screw, 5/16-18 x .750
47 710-0451 Bolt, Carriage, 5/16-18 x .750
48 710-0514 Hex Head Cap Screw, 3/8-16 x 1.00
49 710-0560 Screw, Carriage, 3/8-16 x 1.75
50 710-3184A Hex Head Cap Screw, 3/8-16 x 2.00
51 712- 0417A Flange Nut, 5/8-18
52 912-3017 Hex Nut, 3/8-16
53 732-04406 Extension Spring, Timing Belt
54 732-04452 Extension Spring, Deck Brake
55 938-0347 Shoulder Spacer, .625 ID x .169
56 738-04162A Shoulder Spacer, .8840 x .190
57 942-04154A 2 in 1 Blade
58 754- 04136 Timing Belt, .315 x .787
59 954-04139 Aramid V Belt, 72.2
60 756-04129B Idler Pulley, 4.25" DIA
61 756-0616 Idler Pulley, V-Type, 5.0 DIA
62 787-01440 Timing Idler Bracket
63 711- 0 4 027 Deector Pin
64 726-04009 Push Cap
65 732- 04012 Deector Torsion Spring
66 787-01017A Deector Hinge Bracket
67 634-04349-0931 Wheel, 16 x 4 x 8
68 710-0627 Hex Screw, 5/16-24 x .750
69 736-0242 Washer, Bell, .340 x .872 x .060
70 912- 0641 Nut, Hex, M16-1.5
71 921-04041 Water Nozzle Adaptor
72 736-0225 Washer, Lock, 5/8
73 737-04003D Deck Water Nozzle
— 977S30145 Danger Label (Not Shown)

Cub Cadet CC 760 ES Specifications

General

Drive System	Self-Propelled
Drive Control	Variable Speed
Deck Material	Steel
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Wheel Size (Front)	8 inches
Start Type	Recoil
Cutting Height Range	1.5 to 3.5 inches
